Laguna SUPERBRUSH 36, 1 Ph SUPMX-91367

Applications / Features

• Raw Wood Sanding
• White Wood Sanding
• Break sharp edges
• Blend out minor defects
• Sealer Sanding
• Primer Sanding
• Scuff Sanding
• Profile sanding
• Clean reclaimed wood
• Wire brushing to pull out soft grain to create a textured surface
• Infinitely variable brush speed and conveyor feed rate allows for a wide variety of finishes
• Quickly change brush heads or abrasive loadings
• Fully adjustable tension rollers prevent stock slippage
• Reinforced steel conveyor bed with a poly conveyor belt
• Precision height adjustment
• Bristle Contact Gauge included

These easy-to-use machines have an extremely low learning curve and include quick-change brush heads, infinitely variable brush and conveyor speeds, adjustable tension rollers, and precision height adjustments. Sizes range from 24″ to 49″ with single and/or double brush head offerings to meet all finishing needs.

SuperBrush Single Brush Sanders Benefits

• Faster Output
• Reduced Rework
• Greater Surface Consistency

Sanding Capacity

• Maximum Width - 36″
• Minimum Length - 10″
• Maximum Thickness - 11″ (varies with brush style)
• Minimum Thickness - 1/32″
• Dimensions (H × W × D) - 52″ × 58″ × 35″ (36″ Model)

Brush

• Diameter - 9″ – 11″ typical
• Typical Bristle Length - 1-½″ – 3″

Speed

• Ranged variable, 400–1200 RPM brush

Dust Hood (36″ Model)

• Steel with hinged back
• Three (3) 4″ Vacuum Ports
• 1800 CFM Minimum

Drive Motor (TEFC)

• 24″ & 36″ Models: 5 HP

Power Requirements

• 208–230V, 60Hz; 1 PH, 30 Amp Service; 3 PH, 20 Amp Service

Shipping Weight

• 36″ Model: 605 lbs

Conveyor Motor

• Direct Drive D.C. Motor, infinitely variable, 0–15 FPM
• 36″ Model: 100 in.-lb. torque
