The P|25 Planer sets a new standard for heavy-duty thickness planers. Equipped with a 15HP 3 Phase motor, it delivers consistent power even when planing full 25″ boards. Oversized bearing housings ensure ultra-smooth, quiet performance, while the ShearTec II cutterhead with 6 rows of 4-sided German carbide inserts (174 knives total) guarantees precise and clean cuts. The standard PLC control allows automatic bed height adjustment for exact thickness every time.
Features
- Motor, Cutterhead: 15HP, 3 Phase, 220V, 37A
- Motor, Feed: 3/4 HP, DC Electronically Variable Speed
- Motor, Vertical: 3/4 HP, AC
- DRO (Digital Read Out)
- PLC Programmable Height Setting
- ShearTec II Cutterhead: 6 Row, 174 Insert Knives
Specifications
- Push Button Height Setting & Manual Backup
- Maximum Stock Width: 25″
- Maximum Stock Thickness: 9″
- Minimum Stock Thickness: ⅛″
- Maximum Stock Removal 1-12″ Wide: 6mm (¼″)
- Maximum Stock Removal 12-25″ Wide: 3mm (⅛″)
- Electronic Variable Speed: 10-30 FPM
- Table Size (L x W): 52″ x 26″ (Including Extensions)
- Cutter Head Diameter: 3-½″
- Knives: 174 ShearTec II, 4-Sided, Solid Carbide
- Segmented In Feed Roller: 3″
- Segmented Pressure Bar
- 2 Polished Out Feed Rollers: 3″
- Retractable Table Rollers: Adjustable
- In/Out Feed Cast Extensions Included (L x W): 10″ x 26″
- Dust Port: 5″
- CSA Components
- Weight: 1500 lbs
- Shipping Dimensions (L x W x H): 35″ x 53″ x 60″
| Power Phase | 3 |
|---|---|
| Brand | Laguna |
| Sizes | 39-1/2″ x 31-5/8″ |
| Tool Type | Wood |
