Laguna PX|16 ShearTec: II MPLANPX16-0130

Features

• Infeed and Outfeed Rollers – Assist with material loading and feeding while maintaining a compact footprint.
• Digital Readout – DRO located on the control panel for better ergonomics and precise settings.
• Ergonomic Control Panel – Angled toward the operator for easy access and visibility; modern cabinet design.
• Improved Dust Collection – 4″ dust chute can be positioned left or right for optimal dust management.
• 4-Post Bed Support – Ensures precise and consistent performance with every cut.
• ShearTec II Cutterhead – 6-row carbide insert cutterhead provides superior surface finish on all woods, including hardwoods.
• Serrated Infeed Roller – Mounted close to the cutterhead to minimize snipe.

Specifications

• Motor: 220V, 5HP, 1 Phase, 60Hz, 23 Amp
• CSA Approved: Yes
• Bed Size: 16″ x 21-½″
• Pull-Out Extension: 4″
• Max Depth of Cut: ¼″
• Max Stock Thickness: 8″
• Min Stock Thickness: ¼″
• Min Stock Length: 8″
• Max Stock Width: 16″
• Feed Speed: 16 & 28 FPM
• Dust Port Diameter: 4″ Left & Right
• Cutterhead RPM: 5000
• Cutterhead Diameter: 3″
• Cutterhead Insert #: 108 x 4-Sided Carbide, 6 Row
• No Cord or Plug Supplied
• Thickness Readout: Wixey DRO
• Noise (1m away): 83 dB
• Dimensions Set Up (Approx.): 33″ x 36″
• Dimensions Shipping: 38″ x 30″ x 46″
• Net/Ship Weight: 493/597 lbs
