SKU
MPSP12-5-0135
$9,564.02
The P12|5 was designed as a more compact version of our popular P12|8 and P12|10 panel saws. Featuring a 63″ sliding table design, 5HP main motor, 3/4 HP scoring motor, and a swing-away overhead guard, this machine offers precision cutting in a compact footprint. The telescoping cut-off fence extends to 134″ and has a 51″ rip capacity.
Features
- Main Motor: 5HP
- Scoring Motor: 3/4 HP
- Voltage: 220V, 1 Phase, 60Hz
- Blade Capacity: 12″ – 14″ (300mm – 355mm)
- Max Blade: 14″ / 355mm (minimum height when lowered: 1″ / 25mm)
- Max Scoring Blade: 4-3/4″ / 120mm
- Swing-away overhead guard with quick-change 90° and 45° guards
- Telescoping cut-off fence: extends to 134″
- European style 51″ rip fence with micro adjustment
- Heavy-duty anodized aluminum crosscut fence with flip-stops
- Soft start motor to minimize initial amperage draw
- Includes hold-down clamp, rip shoe, and push handle
Specifications
- Motor: 5HP Main, 3/4 HP Scoring
- Voltage: 220V, 1 Phase, 60Hz
- Blade Capacity: 12″, 14″ (300mm, 355mm)
- Max Cutting Height 90°: 14″ Blade – 4-1/2″ (115mm), 12″ Blade – 3-1/2″ (90mm)
- Max Cutting Height 45°: 14″ Blade – 2-3/4″ (70mm), 12″ Blade – 2-3/8″ (62mm)
- Main Blade Speed: 4000 RPM
- Scoring Blade Speed: 8000 RPM
- Dust Collection Port: 4″ (100mm)
- Sliding Table: 63″ (1600mm) x 12″ (305mm)
- Main Cast Table: 21-1/2″ x 35-1/4″
- Rip Fence: 51″ (1300mm) with micro adjustment
- Rip Fence Bar: 1-5/8″ (40mm) solid steel, micro polished
- Crosscut Fence: Flip-stops, inch/metric readout
- Crosscut Fence Max Collapsed: 73″, Max Extended: 134″
- Included Accessories: Push handle, rip shoe, hold-down clamp, 32″ x 12″ steel extension table
- Shipping Dimensions: 83″ x 46″ x 46″
- Weight (Net / Ship): 1405 / 1525 lbs
| Power Phase | 1 |
|---|---|
| Brand | Laguna |
| Voltage | 220 V |
| Sizes | 12" |
| Tool Type | Wood |
