Laguna 37X2 DOUBLE DRUM SANDER WITH CASTERS, 220V – 1Ph SUPMX-937003

Features

• INTELLISAND Technology: Automatically adjusts conveyor speed based on load
  • Prevents gouging, damaging, or burning stock
  • Provides consistent finish even with varying grain pattern and density
  • Greatly increases abrasive planing and dimensioning speed
• Flatness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel cross sections, flatness to less than .010″ across width of sander
• Abrasive conveyor belt provides excellent grip for raw wood, accommodating shorter or thinner stock
• Patented Abrasive Attachment System effectively tensions abrasive wraps, preventing loose abrasive and overlap
• Easiest access to abrasive fastening system; extra space eliminates need for special tools
• Self-cooling drum prevents overheating and extends abrasive life

Sanding Capacity

• Maximum Width - 37″
• Minimum Length - 3-½″
• Maximum Thickness - 12″
• Minimum Thickness - 1/32″
• Dimensions (H × W × D) - 43″ × 58″ × 31″

Machine Specs

• Drum (Extruded Aluminum) - 5″ × 37″
• Drum Speed - 1740 RPM
• Dust Hood - Steel Hood, Hinged at Back, (3) 4″ Vacuum Ports, Min 1000 CFM Recommended
• Ball Bearings (1″) - 4 sealed and permanently lubricated
• Conveyor Motor - 100 in.-lb. torque, direct drive D.C. motor, ranged variable 0–15 FPM
• Drive Motor (TEFC) - 5 HP
• Power Requirements - 208–230V, 60Hz, 1 Phase, 30 Amp Service
• Shipping Dimensions (L × W × H) - 62″ × 52″ × 45″
• Casters Included - Yes
• Cord & Plug Included - No
