Constructed using the Certified Meehanite® casting process for added durability, the JET ZH-Series 4-1/8” Spindle Bore Lathes provide consistent and reliable operation. Features include a clutch operated headstock with all headstock gears hardened and ground, a universal gearbox, fully integrated coolant system, and a rapid traverse on the apron that makes the ZH-Series perfect for high-output production applications. These are the features you've come to expect in a JET Lathe that is backed by the industry-leading JET Two Year Warranty.
Features
- 12" 3 Jaw scroll chuck with top reversing jaws
- 2 Steady rests with roller bearings
- Bed ways are induction hardened and ground for durability
- E-Stop on Carriage for added safety
- Electronic Chuck Key Holder
- Fitted top mats to hold tooling
- Full Length Splash Guard
- Heavy-duty tailstock and quill
- Large easy to use foot brake
- Rapid power traverse to cross slide and carriage
Specifications
- Stock Number: JT9-321891
- Carriage Travel (In.): 108-1/4
- Compound Slide Travel (In.): 5-1/2
- Drive: Geared Head
- Length of Gap (In.): 8
- Max Tool Size (In.): 1-1/4 x 1-1/4
- Model Number: GH-26120ZH
- Motor (HP): 10 HP, 230/460, 3 Ph
- Number of Inch Threads: 48.0000
- Number of Longitudinal and Cross Feed Rates: 65
- Number of Metric Threads: 22.0000
- Number of Spindle Speeds: 12
- Overall Dimensions (L x W x H) (In.): 178 x 43 x 57
- Prop 65: Cancer and Reproductive Harm
- Range of Cross Feeds (IPR): .0040 - .0404
- Range of Inch Threads (TPI): 2-30
- Range of Longitudinal Feeds (IPR): .0023 - .0937
- Range of Metric Threads: 1 - 14
- Range of Spindle Speeds (RPM): 36 - 1,600
- Size: 26 x 120
- Spindle Bore (In.): 4-1/8
- Spindle Mount: D1-8
- Spindle Taper with Sleeve: MT-5
- Steady Rest Capacity (In.): Small 25/32 - 4-29/32, Large 3-15/16 - 9-7/16
- Style (Type): Engine - Large Spindle Bore
- Swing Over Bed (In.): 26
- Swing Over Cross Slide (In.): 16-1/2
- Swing Through Gap (In.): 34
- Tailstock Spindle Travel (In.): 6
- Taper in Tailstock Spindle: MT-5
- Warranty: 2 Year
- Width of Bed (In.): 16
- Gross Weight: 9362.0
- Net weight: 7500.0
| Brand | Jet |
|---|---|
| Warranty | 2 Year |
| Tool Type | Metal |
