Jet GH-26120ZH With ACU-RITE 203 DRO JT9-321892

Specifications

• Stock Number: JT9-321892
• Carriage Travel (In.): 108-1/4
• Compound Slide Travel (In.): 5-1/2
• Drive: Geared Head
• Length of Gap (In.): 8
• Max Tool Size (In.): 1-1/4 x 1-1/4
• Model Number: GH-26120ZH
• Motor (HP): 10 HP, 230/460, 3 Ph
• Number of Inch Threads: 48.0000
• Number of Longitudinal and Cross Feed Rates: 65
• Number of Metric Threads: 22.0000
• Number of Spindle Speeds: 12
• Overall Dimensions (L x W x H) (In.): 178 x 43 x 57
• Prop 65: Cancer and Reproductive Harm
• Range of Cross Feeds (IPR): .0040 - .0404
• Range of Inch Threads (TPI): 2-30
• Range of Longitudinal Feeds (IPR): .0023 - .0937
• Range of Metric Threads: 1 - 14
• Range of Spindle Speeds (RPM): 36 - 1,600
• Size: 26 x 120
• Spindle Bore (In.): 4-1/8
• Spindle Mount: D1-8
• Spindle Taper with Sleeve: MT-5
• Steady Rest Capacity (In.): Small 25/32 - 4-29/32, Large 3-15/16 - 9-7/16
• Style (Type): Engine - Large Spindle Bore
• Swing Over Bed (In.): 26
• Swing Over Cross Slide (In.): 16-1/2
• Swing Through Gap (In.): 34
• Tailstock Spindle Travel (In.): 6
• Taper in Tailstock Spindle: MT-5
• Warranty: 2 Year
• Width of Bed (In.): 16
• Gross Weight: 9471.0
• Net weight: 9362.0

Features

• 12" 3 Jaw scroll chuck with top reversing jaws
• 2 Steady rests with roller bearings
• Bed ways are induction hardened and ground for durability
• E-Stop on Carriage for added safety
• Electronic Chuck Key Holder
• Fitted top mats to hold tooling
• Full Length Splash Guard
• Heavy-duty tailstock and quill
• Large easy to use foot brake
• Rapid power traverse to cross slide and carriage
